Description

Intergas HRE & ECO RF Inner Flue Seals Kit

Intergas HRE & ECO RF Inner Flue Seals Kit comprises of number 1, 4, 12 & 15 on the exploded diagram and fits the following Intergas boilers:

• Intergas HREÿCompact 18 OV
• Intergas HREÿCompactÿ24 OV
• Intergas HREÿCompactÿ30 OV
• Intergas HREÿCompactÿ18 SB
• Intergas HREÿCompactÿ24 SB
• Intergas HREÿCompactÿ30 SB
• Intergas HREÿCompactÿ40 SB
• Intergas HRE Combi Compact 24/18
• Intergas HRE Combi Compact 28/24
• Intergas HRE Combi Compact 36/30
• Intergas HRE Combi Compact 36/40
• Intergas ECO RF 24
• Intergas ECO RF 30
• Intergas ECO RF 36

NOTE: The Intergas Inner Flue Seals Kit comprises of 1x Intergas Condensate Trap Grommet (878577 number 1 on exploded diagram), 1x Intergas Condensate Collector Inner Seal 76mmÿ (878147 number 4 on exploded diagram), 1x Intergas Flue Pipe O-Ring Seal 68mm x 4mm (878537 number 15 on exploded diagram) & 1x Intergas Flue Pipe Inner Seal Ring 70mm x 82mm (878547 number 12 on exploded diagram).
